Technical data
| Additional data | |
|---|---|
| No-load speed* | 10.000 – 30.000 rpm |
| Rated input power* | 650 |
| Tool holder* | Collets up to 8 mm diameter |
| Power output | 380 |
| Spindle collar diameter | 43 |
| Weight | 1.6 |
| Tool dimensions (length) | 375 |
| Tool dimensions (height) | 75 |
| Max. collet diameter | 8 mm (only 6 mm included) |
| Max. grinding tool diameter | 50 |
| Spanner size of locking nut | 19 |
| Spanner size of grinding spindle | 13 |
| Switch | 2-way |
| Total vibration values (Surface grinding up to diameter of 25) | |
|---|---|
| Vibration emission value ah | 6 |
| Uncertainty K | 1.5 |
| Total vibration values (Surface grinding up to diameter of 50) | |
|---|---|
| Vibration emission value ah | 14 |
| Uncertainty K | 1.5 |
* Highlighted Data
The A-rated noise level of the power tool is typically as follows: Sound pressure level 77 dB(A); Sound power level 88 dB(A). Uncertainty K= 3 dB.
Advantages
Perfect handling for demanding grinding work
- Powerful 650-watt motor for fast work progress with soft start
- Long, slim grinding spindle – particularly suitable for use in hard-to-reach areas
- KickBack Control: detects when the tool is jammed and shuts it down immediately – for a high level of user protection
Functions
What’s Included in this Package
with collet
Order number:
0 601 221 100
- Collet 6 mm 2 608 570 084
- 2 x open-ended spanners WAF 19 (spare part number 3 607 950 024)
