Impact Drill
Your Selection
Order number: 0 601 218 671
Find a local dealerThis product includes
Show less
Show more
Additional data |
|
---|---|
Rated input power | 701 W |
Weight | 1.9 kg |
No-load speed, 1st gear | 0 – 3.000 rpm |
Power output | 351 W |
Impact rate at no-load speed | 0 – 48.000 bpm |
Drill spindle connecting thread | 1/2"-20 UNF |
Chuck capacity, min./max. | 1=5 – 13 mm |
Drilling range |
|
---|---|
Drilling diameter in wood | 30 mm |
Drilling diameter in concrete | 16 mm |
Drilling diameter in steel | 12 mm |
Drilling diameter in masonry | 18 mm |
Total vibration values (Drilling in metal) |
|
---|---|
Vibration emission value ah | 2.7 m/s² |
Uncertainty K | 1.5 m/s² |
Total vibration values (Impact drilling in concrete) |
|
---|---|
Vibration emission value ah | 23 m/s² |
Uncertainty K | 3.5 m/s² |
Total vibration values (Screwdriving) |
|
---|---|
Vibration emission value ah | 2.5 m/s² |
Uncertainty K | 1.5 m/s² |
Noise/vibration information |
|
---|---|
Sound pressure level | 98 dB(A) |
Sound power level | 109 dB(A) |
Uncertainty K | 3 dB |
Drilling in metal |
|
---|---|
Vibration emission value ah | 2.7 m/s² |
Uncertainty K | 1.5 m/s² |
Impact drilling in concrete |
|
---|---|
Vibration emission value ah | 23 m/s² |
Uncertainty K | 3.5 m/s² |
Screwdriving |
|
---|---|
Vibration emission value ah | 2.5 m/s² |
Uncertainty K | 1.5 m/s² |
The A-rated noise level of the power tool is typically as follows: Sound pressure level 98 dB(A); Sound power level 109 dB(A). Uncertainty K= 3 dB.
