Additional data | |
---|---|
No-load speed | 30,000 rpm |
Rated input power | 500 W |
Tool holder | Collets up to 8 mm diameter |
Power output | 280 W |
Spindle collar diameter | 38 mm |
Weight | 1.7 kg |
Tool dimensions (length) | 383 mm |
Tool dimensions (height) | 75 mm |
Max. collet diameter | 8 mm (only 6 mm included) |
Max. grinding tool diameter | 40 mm |
Spanner size of locking nut | 19 mm² |
Spanner size of grinding spindle | 13 mm² |
Switch | PROtection Switch |
Total vibration values (Surface grinding up to diameter of 25) | |
---|---|
Vibration emission value ah | 6 m/s² |
Uncertainty K | 1.5 m/s² |
Total vibration values (Surface grinding up to diameter of 50) | |
---|---|
Vibration emission value ah | 20 m/s² |
Uncertainty K | 1.5 m/s² |
