Technical data
| Additional data | |
|---|---|
| Battery voltage* | 12 V |
| Torque (soft/hard/max.) | 18/30/- Nm |
| No-load speed (1st gear / 2nd gear) | 0 – 420 / 0 – 1,600 rpm |
| Battery type | Lithium-ion |
| Chuck capacity, min./max. | 0.8 / 10 mm |
| Weight excl. battery* | 0.72 kg |
| Torque settings | 20+1 |
| Tool holder | Three-jaw chuck |
| Drilling diameter | |
|---|---|
| Max. drilling diameter in aluminium | 10 mm |
| Max. drilling diameter in wood | 20 mm |
| Max. drilling diameter in steel | 10 mm |
| Max. screw diameter* | 8 mm |
| Screw diameter | |
|---|---|
| Max. drilling diameter in aluminium | 10 mm |
| Max. drilling diameter in wood | 20 mm |
| Max. drilling diameter in steel | 10 mm |
| Max. screw diameter* | 8 mm |
| Total vibration values (Drilling in metal) | |
|---|---|
| Vibration emission value ah | 1.4 m/s² |
| Uncertainty K | 1.5 m/s² |
| Total vibration values (Screwdriving) | |
|---|---|
| Vibration emission value ah | 0.5 m/s² |
| Uncertainty K | 1.5 m/s² |
* Highlighted Data
The A-rated noise level of the power tool is typically as follows: Sound pressure level dB(A); Sound power level dB(A). Uncertainty K= dB.
Advantages
Impressive features, powerful results
- High-end features within reach when screwdriving and drilling
- Brushless motor for longer tool life
- High torque and rapid drilling speeds for quick and powerful results
Functions
What’s Included in this Package
in carrying case
Order number:
0 601 9G9 0L0
- 2 x battery GBA 12V 2.0Ah 1 600 A00 F6X
- Quick charger GAL 12V-40 Professional 1 600 A01 B8Z
- Carrying case
