Technical data
| Additional data | |
|---|---|
| Rated input power* | 1,400 W |
| Saw blade diameter* | 184 mm |
| Saw blade bore diameter | 20 mm |
| No-load speed | 5,200 rpm |
| Weight | 4.1 kg |
| Tool dimensions (width) | 385 mm |
| Tool dimensions (length) | 260 mm |
| Tool dimensions (height) | 280 mm |
| Cutting depth | |
|---|---|
| Max. cutting capacity in wood (90°)* | 67 mm |
| Max. cutting capacity in wood (45°) | 49 mm |
* Highlighted Data
The A-rated noise level of the power tool is typically as follows: Sound pressure level dB(A); Sound power level dB(A). Uncertainty K= dB.
Advantages
Speed and comfort redefined in its class for continuous use.
- Strong and resistant for heavy work on site or applications in the workshop. Perfect for cutting hardwood.
- High cutting speed guaranteeing increased productivity at work.
- Deeper cutting capacity. Depth adjustment for cuts up to 67 mm deep.
Functions
What’s Included in this Package
with saw blade
Order number:
0 601 623 071
- Hex key WAF 5
- Saw blade
- Vacuum adapter
- Rip fence
- Folding box
