Technical data
| Additional data | |
|---|---|
| Battery voltage* | 3.6 V |
| Battery type | Lithium-ion |
| Torque (soft/hard/max.) | 2.5/5/- Nm |
| No-load speed (1st gear / 2nd gear) | – 360 rpm |
| Chuck capacity, min./max. | 6.35 mm |
| Weight excl. battery* | 0.31 kg |
| Screw diameter | |
|---|---|
| Max. screw diameter* | 5 mm |
| Total vibration values (Screwdriving) | |
|---|---|
| Vibration emission value ah | 2.5 m/s² |
| Uncertainty K | 1.5 m/s² |
* Highlighted Data
The A-rated noise level of the power tool is typically as follows: Sound pressure level 70 dB(A); Sound power level 80 dB(A). Uncertainty K= 3 dB.
Advantages
Minimum Effort, Maximum Efficiency
- Easy to control – tool stops immediately after deactivation via electronic brake
- Dual-activation mode – simply push tool or press button to begin
- Mechanical clutch with 5 torque settings and maximum performance mode
Functions
What’s Included in this Package
in carrying bag
Order number:
0 601 9H2 100
- Carrying case
- Cardboard box
- Micro USB cable 1 607 000 CG9
- 1 x screwdriver bit PH1 2 608 521 M10
- 1 x screwdriver bit PH2 2 608 521 M11
