Technical data
| Additional data | |
|---|---|
| Rated input power* | 800 W |
| Weight | 2.6 kg |
| Tool dimensions (length) | 347 mm |
| No-load speed | 0 – 1,100 / 3,000 rpm |
| Power output | 420 W |
| Rated speed | 740 / 1,930 rpm |
| Rated torque | 4.8 / 1.8 Nm |
| Drill spindle connecting thread | 1/2" – 20 UNF |
| Chuck capacity, min./max. | 1.5 – 13 mm |
| Tool dimensions (width) | 217 mm |
| Impact rate at no-load speed | 0 – 17,600 / 48,000 bpm |
| Max. torque | 24.0 / 14.0 Nm |
| Drilling range | |
|---|---|
| Drilling diameter in concrete | 16 / 12 mm |
| Drilling diameter in wood* | 35 / 22 mm |
| Drilling diameter in steel | 13 / 6 mm |
| Drilling dia. in stone | 18 / 14 mm |
| Drilling diameter in masonry* | 18 / 14 mm |
| Total vibration values (Drilling in metal) | |
|---|---|
| Vibration emission value ah | 3 m/s² |
| Uncertainty K | 1.5 m/s² |
| Total vibration values (Impact drilling in concrete) | |
|---|---|
| Vibration emission value ah | 17.5 m/s² |
| Uncertainty K | 1.7 m/s² |
| Total vibration values (Screwdriving) | |
|---|---|
| Vibration emission value ah | 2.5 m/s² |
| Uncertainty K | 1.5 m/s² |
* Highlighted Data
The A-rated noise level of the power tool is typically as follows: Sound pressure level 96 dB(A); Sound power level 107 dB(A). Uncertainty K= 3 dB.
Advantages
The fastest and most versatile tool in its class
- Powerful 2-speed impact drill (800 W) for the fastest work progress
- Sturdy metal gear housing for a long lifetime
- Anti-rotation mechanical overload clutch for a high level of work safety
Functions
What’s Included in this Package
in carrying case with accessory set, (Voltage 240 V)
Order number:
0 601 1A2 190
- Carrying case 2 605 438 524
- Voltage 240 V
- Depth stop 210 mm 2 603 001 019
- Keyed chuck 13 mm (spare part number 1 617 S00 W5H)
- Auxiliary handle (spare part number 1 617 S00 VV1)
