| Impact rate at rated speed | ||
|---|---|---|
| 0 – 4,250 bpm | 0 – 4,350 bpm | |
| Rated speed | ||
| 0 – 950 rpm | 0 – 980 rpm | |
| Battery voltage | ||
| 18.0 V | 18.0 V | |
| Weight excl. battery | ||
| 3 kg | 2.6 kg | |
| Tool holder | ||
| SDS plus | SDS plus | |
| Packaging dimensions (width x length x height) | ||
| 245 x 475 x 109 mm | 288 x 573 x 114 mm | |
| BITURBO | ||
| No | - | |
| Impact energy nominal | ||
| 3.4 J | - | |
| Impact energy | ||
| - | 2.5 J | |
| Drilling dia. in concrete with hammer drill bits | ||
|---|---|---|
| 4 – 28 mm | 4 – 26 mm | |
| Opt. app. range in concrete with hammer drill bits | ||
| 8 – 16 mm | 8 – 16 mm | |
| Vibration emission value ah | ||
|---|---|---|
| 10.1 m/s² | 16.7 m/s² | |
| Uncertainty K | ||
| 1.5 m/s² | 1.5 m/s² | |
| Vibration emission value ah | ||
|---|---|---|
| 2.5 m/s² | - | |
| Uncertainty K | ||
| 1.5 m/s² | - | |
| Vibration emission value ah | ||
|---|---|---|
| 2.5 m/s² | - | |
| Uncertainty K | ||
| 1.5 m/s² | - | |
| Vibration emission value ah | ||
|---|---|---|
| 7.2 m/s² | 10.9 m/s² | |
| Uncertainty K | ||
| 1.5 m/s² | 1.5 m/s² | |
|
|
|
